RICOH Portable LCD 150BW 15.6" 16:9 1920x1080 OLED 1ms 100,000:1 Wireless/Miracast USB-C/Li-Ion Battery Powered

https://www.pfu-emea.ricoh.com/en-gb/hardware/meeting-devices/portable-monitor-150bw

• Battery powered
• 715g: ultra-lightweight - easy to carry, set up and use anywhere
• 15.6-inch OLED screen for high-quality, high contrast vivid images
• Fully wireless capabilities — 1-step wireless connection with the Auto Cast app
• 10-point multi-touch touchscreen — with touch-back function
• Multicast capability without external dongle — simultaneously connect with up to 32 units

The powerfully RICOH Portable Monitor 150BW provides an accessible second screen experience that’s easy to carry, set up and use anytime, anywhere. At just 715g, it’s ultra-lightweight for such a large, high-quality, high contrast 15.6-inch OLED panel.

The Portable Monitor offers value for both one-to-one meetings or larger groups, and for face-to-face or hybrid meeting formats, whether in or out of the office. Using the 10-point multi-touch touchscreen (with or without stylus), users can work collaboratively, quickly and clearly by highlighting text and graphics on shared content. And it’s all backed by the reassurance of quality, performance, and reliability of a trusted technology brand.

Product Name		RICOH Portable Monitor 150BW
Energy efficiency
Security		Link to PSTI Compliance Statement
Display panel	Display method	OLED (Organic Light Emitting Diode)
	Maximum resolution	1920 x 1080
	Brightness (max)*1	300 nit (=cd/m2)
	Contrast	1:100,000
	Display colours	8bit+2bit FRC (maximum number of colours: Approx. 1.07 billion colours)
	Panel size	15.6 inches
	Refresh rate	60Hz
	Colour gamut	DCI P3 100%
	Viewing angle	85° or higher
	Response time	1ms
	Blue light cut	Eye Care Display certified
	Number of simultaneous display units	Max. 2 units (wireless)
Touch panel	Protective glass	Toughened glass, AF (anti-fingerprint) coating
	Detection method	Active electrostatic coupling method (AES2.0)
	10-point multi-touch*2	Wired/ Wireless connection: Supported (Windows®/ Android™)
Interfaces	Back side	USB Type-C® 2 (External power supply/ DisplayPort™ signal input function supported)
	Screen wireless communication method, Encryption	Miracast®*3 WPA2™ PSK
	Supported wireless LAN standard	IEEE802.11 b/g/n (2.4 GHz), IEEE802.11 a/n/ac (5 GHz)
Audio	Built-in speaker	1.5W x 2
Power supply (external)	Input method	USB Power Delivery (USB Type-C® powered)
	Input*4	Max. 45W (5V/3A, 9V/3A, 15V/3A, 20V/2.25A)
	Output (power pass through)*5	Max. 25W (5V/0.9A, 9V/0.77A, 15V/1.66A, 20V/1.25A)
	ON mode power consumption	15.5 W or less
	Standby mode power consumption	0.2 W or less
Internal battery	Type	Lithium-ion battery
	Capacity	3740mAh
	Charging time	Approx. 2.5 hours*6
	Operating time (when fully charged)	Continuous operating time: 3 hours*7
Environment	Operating temperature	0~35°C
	Operating humidity	10-80% (without condensation)
Continuous operating time		20 hours*8
Weight (main unit only)		1.58lb (715g)
Dimensions (main unit only) W x D x H		356.0 x 10.8 x 221.7mm (thinnest part: 4.8mm)
Screen installation angle	Landscape orientation	Free stop (Approx. 75–16°), Recommended angle for writing: Approx. 16°
	Portrait orientation	Approx. 70°
Certification supported Certificates		Energy Star, Act on Promoting Green Purchasing
Main unit warranty period		3 years Warranty Advance Exchange Service

^*1The brightness varies depending on the input mode video adjustment settings, etc. Brightness will also deteriorate over time. It does not maintain a constant brightness.
^*2Touch-and-handwriting features and display accuracy are essentially dependent on the handling of OS or each application. Handwritten images may appear erroneously due to Miracast® process properties when wirelessly connected.
^*3SSE (Smart Streaming Engine) is used. The free software products listed below are required to connect wirelessly over Mac PC and iPhone.
^*4If the input power is insufficient according to the specifications of this unit, the operation may become unstable.
^*5Depending on PC or smartphone specifications, pass-through may not be possible or there may be restrictions on the operation of the unit.
^*6When charging in an environment of 16 to 35 ° C.
^*7It is a guideline on output condition according to our measuring method, and it changes according to operating conditions.
^*8Due to the nature of organic EL, there is a possibility that an afterimage may remain on the display when a still image or still character is displayed for a long time. This product is not designed for continuous operation of more than 20 hours. Use of the product beyond the specifications of continuous operation time may shorten the life of the main unit. It is not guaranteed to connect to all PCs and smartphones. The wireless connection may become unstable during high-load operation on a PC or smartphone or due to the surrounding radio wave conditions.

Package contents

• RICOH Portable Monitor 150BW
• 1 x USB Type-C® cable
• 4 x Cable clamps
• Sleeve case
• Warranty card
• Read This First
• Quick Guide
• Licence Code for "RICOH Monitor Multicast for Windows®"
